Durable, single-board construction, Scratch-resistant tempered glass exit window, Accurate first-time capture of 1D bar codes, Wide working range, Multiple on-board interfaces, Plug-and-play, with universal cable, Intuitive design, Ergonomic, lightweight design, Advanced Data Formatting (ADF).
| Decode capability |
1D, See data sheet for full list of supported symbologies |
| Depth of Field |
From contact to 17 in./43 cm on 100% U.P.C./EAN symbols |
| Interfaces supported |
IBM, Keyboard wedge, RS-232, Synapse, USB, Wand |
| Minimum resolution |
20% minimum reflective difference |
| Pitch |
2 +/-65 degrees (Controlled by dropping or raising the wrist) |
| Roll (Tilt) |
1 +/-30 degrees (Controlled by rotating the wrist clockwise or counterclockwise) |
| Scan pattern |
Single line |
| Skew (Yaw) |
3 +/-60 degrees (Controlled by rotating the wrist from left to right or vice versa) |
| Technology |
Laser |
| EMC |
FCC Part 15 Class B, ICES 003 Class B |
| Electrical Safety |
UL 60950-1, C22.2 No. 60950-1, EN 60950-1, IEC 60950-1 |
| Environmental |
RoHS Directive 2002/95/EEC |
| Laser Safety |
EN 60825-1, IEC 60825-1, 21CFR1040.10 |
| Operating temperature |
32° ~ 122°F (0° ~ 50°C) |
| Storage temperature |
-40° ~ 158°F (-40° ~ 70°C) |
| Power source |
Host power or external power supply (depends on host type) |
| Corded |
Yes |
| Voltage and current |
5 volts +/- 10% at 130 mA typical, 175 mA max |
| Dimension (WHD) |
152(H) x 63(W) x 84(D) mm |
| Weight |
146 gram |
| Alnect Care Warranty |
30 Hari |
| Standard Warranty |
180 Hari |
| Manufacturer website |
http://www.motorola.com/ |
|
