PRODUCT OVERVIEW
Wireless N Outdoor Access Point TP-Link EAP110-Outdoor dirancang untuk penggunaan Wi-Fi diluar ruang. Memiliki kecepatan Wi-Fi hingga 300Mbps dengan teknologi 2x2 MIMO dan memiliki daya transmisi yang tinggi serta high-gain antena untuk cakupan area yang lebih luas. Selain itu, TP-Link EAP110-Outdoor ini sudah dilengkapi dengan passive PoE (Power over Ethernet) dan desain yang simple untuk memudahkan pemasangan serta tahan lama terhadap kondisi cuaca diluar bangunan yang ektrim. Dilengkapi dengan Auranet Controller Software untuk pengaturan administrasi yang lebih mudah, hingga ratusan EAP dan medukung pengelolaan VLAN untuk penyempuranaan pengelolaan jaringan.
DETAIL SPESIFICATION
Wireless N Speed up to 300Mbps, Simple Mounting Design on any Wall or Pole, Passive PoE Supported, Weatherproof Enclosure, 15KV ESD and 6KV Lightning Protection, Free Controller Software for easy centralized management of hundreds of EAPs, Captive portal provides one convenient method of authentication for Wi-Fi guests, Rate Limit on per SSID to Restrict the Bandwidth of Each Client, Load Balance and Reboot Schedule Supported, WPA/WPA2-enterprise and 802.1X with RADIUS Secure Authentication, Multi-SSID Divides Multiple Wireless Network for Different Users, Multiple Operating Modes including Managed AP and Standalone AP Satisfy Different Application Conditions.
| PC Connectivity |
Fast Ethernet (RJ-45) Port *1（Support Passive PoE) |
| Wifi Signal Capability |
IEEE 802.11n/g/b |
| Work Mode |
Managed AP and Standalone AP |
| Frequency Range |
2.4GHz |
| Wireless Security |
64/128/152-bit WEP / WPA / WPA2-Enterprise,WPA-PSK / WPA2-PSK |
| Antenna Type |
2* 5dBi External Omni waterproof |
| Wireless Transmit Power |
CE：<20dBm, FCC: <27dBm |
| Operating Temperature |
30℃~65℃ (-22℉~149℉) |
| Operating Humidity |
10%~90% non-condensing |
| Storage Temperature |
-40℃~70℃ (-40℉~158℉) |
| Storage Humidity |
5%~90% non-condensing |
| Power Consumption |
6.3W |
| Input Voltage Range |
Localized to Country of Sale |
| Output Voltage Range |
24VDC / 0.6A Passive PoE Supply |
| Support Operating System |
Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10 |
| Other Features |
Certification: CE/FCC/RoHS, LED ON/OFF Control, Email Alerts, Web-based Management |
| Dimension (WHD) |
209 × 95 × 42.6 mm |
| Alnect Care Warranty |
30 Hari |
| Standard Warranty |
90 Hari |
| Others |
Pole/Wall Mounting (Kits included), Watch Dog Supported, Management VLAN, Telnet |
| Manufacturer website |
http://www.tp-link.com/ |
