PRODUCT OVERVIEW
Access Point atau AP keluaran TP-Link ini hadir dengan penempatan yang sangat fleksibel dengan pemasangan PoE yang mudah. TP-Link EAP110 adalah sebuah perangkat pemancar sinyal WiFi yang dapat diletakkan seperti layaknya lampu langit-langit ruangan yang membuatnya mudah untuk diintegrasikan di setiap permukaan dinding atau langit-langit ruangan tamu, ruang keluarga bahkan teras rumah untuk berbaur dengan sebagian besar dekorasi interior rumah atau kantor. AP ini mendukung PoE pasif untuk instalasi yang mudah hingga 100meter untuk membuat penyebaran sinyal WiFi yang lebih mudah dan fleksibel. Dilengkapi fitur EAP110 802.11n Wi-Fi dan 2x2 teknologi MIMO dengan kecepatan nirkabel hingga 300Mbps dan dengan chipset Qualcomm Atheros 560MHz memastikan kehandalan jangkauan nirkabel yang luar biasa. Dengan desain pemasangan yang mudah, power supply PoE, fitur Cluster, perangkat lunak manajemen terpusat, Captive Portal, manajemen Auto RF, dan perangkat keras bisnis, access point ini dirancang khusus untuk high-density, lingkungan bisnis yang paling menuntut, termasuk sekolah, hotel, dan perusahaan.
DETAIL SPESIFICATION
300Mbps Wireless N Ceiling Mount Access Point, EAP Controller Software Enables Sdministrators to Easily Manage Hundreds of EAPs, Supports passive PoE for Convenient Installation up to 100 meters, Ceiling Mounting Design with Chassis make it Easy to Deploy on a Wall or Ceiling, Captive Portal Provides One Convenient Method of Authentication for Wi-Fi Guests, Multi-SSID Divides Multiple Wireless Networks for Different Users, Enterprise Class Wi-Fi Security Help to Decrease Network Security Threats, 802.11n Wi-Fi and 2x2 MIMO Technology, Qualcomm Atheros 560MHz Chipsets to Ensures Incredible Wireless Coverage and Reliability, Built-In Kensington Lock Slot, Supports Watch Dog.
PC Connectivity |
Fast Ethernet (RJ-45) Port x1 (Support Passive PoE) |
Wifi Signal Capability |
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
Work Mode |
Access Point Only |
Frequency Range |
2.400 - 2.4835GHz |
Wireless Security |
64/128/152-bit WEP / WPA / WPA2-Enterprise,WPA-PSK / WPA2-PSK |
Antenna Type |
Internal 2x 3dBi Omni |
Wireless Transmit Power |
CE: <20dBm, FCC: <26dBm |
Operating Temperature |
0℃~40℃ (32℉~104℉) |
Operating Humidity |
10%~90% non-condensing |
Storage Temperature |
-40℃~70℃ (-40℉~158℉) |
Storage Humidity |
5%~90% non-condensing |
Power Consumption |
7.7W |
Input Voltage Range |
Localized to Country of Sale |
Output Voltage Range |
24VDC / 1A Passive PoE Supply |
Support Operating System |
Microsoft Windows 10/8/7/Vista/XP |
Other Features |
Physical Security Lock: Kensington Lock Slot, Watch Dog Ready, Certification: CE/FCC/RoHS |
Dimension (WHD) |
180 x 180 x 47.5 mm |
Alnect Care Warranty |
30 Hari |
Standard Warranty |
90 Hari |
Others |
Package Contents: EAP110, PoE, Power Cord, Mounting Kits, Resource CD, Installation Guide |
Manufacturer website |
http://www.tp-link.com/ |
