Camera :

Image Sensor：1/2.8" progressive scan CMOS

Min. Illumination：Color: 0.01 Lux @(F1.2, AGC ON), 0.028Lux @ (F2.0, AGC ON)

Shutter Speed：1/3 s to 1/100, 000 s

Slow Shutter：Yes

Auto-Iris：No

Day &Night：IR cut filter

Digital Noise Reduction：3D DNR

WDR：DWDR

Angle Adjustment (Bracket)：Pan: 0° to 360°, tilt: 0° to 180°, rotation: 0° to 360°

Lens :

Focal length：2.8 mm, 4 mm

Aperture：F2.0

Focus：Fixed FOV：2.8 mm, horizontal

FOV 114.8°, vertical FOV 62°, diagonal FOV 135.5° 4 mm, horizontal FOV 86°, vertical FOV 46.5°, diagonal FOV 102.5°

Lens Mount：M12

IR:

IR Range：Up to 30 m

Wavelength：850 nm

Compression Standard :

Video Compression：Main stream: H.265+/H.265/H.264+/H.264 Sub stream: H.265/H.264/MJPEG

H.264 Type：Main Profile/High Profile/Baseline Profile

H.265 Type：Main Profile Video Bit Rate：32 Kbps to 8 Mbps

Smart Feature-set

Region of Interest：1 fixed region for main stream

Image Max. :

Resolution：1920 × 1080

Main Stream：50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720)

Max. Frame Rate：60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)

Sub-stream：50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)

Max. Frame Rate：60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)

Image Enhancement：BLC, 3D DNR

Image Setting：Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser Day/Night Switch：Auto, scheduled, day, night

Network :

Alarm Trigger：Motion detection, video tampering alarm, illegal login

Protocols：TCP/IP, ICMP, HTTP, HTTPS, DHCP, DNS, RTP, RTSP, RTCP, NTP, IGMP, QoS, UDP General Function：Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark

Firmware Version：V5.5.83

API：ONVIF (PROFILE S), ISAPI Simultaneous Live View：Up to 6 channels

User/Host：Up to 32 users 3 levels: Administrator, Operator, and User

Client：HiLookVision PC Client, HiLookVision App

Web Browser：IE8+, Chrome 41.0-44, Firefox 30.0-51, Safari 8.0-11

Interface Communication Interface：1 RJ45 10M/100M self-adaptive Ethernet port

General :

Operating Conditions：-30 °C to 60 °C (-22 °F to 140 °F), humidity: 95% or less (non-condensing)

Power Supply：12 VDC ± 25%, 5.5 mm coaxial power plug

PoE (802.3af, class 3)

Power Consumption and Current:12 VDC, 0.3 A, Max: 3.5 W PoE: (802.3af, 36 V to 57 V), 0.2 A to 0.1 A, Max: 4.5 W

Protection Level：IP67

Material Without –M model: Front cover: metal, camera body: plastic, bracket: plastic -M model: Front cover: metal, camera body: metal, bracket: metal Dimensions Without –M model: Ø 70 mm × 186.3 mm (Ø 2.8" × 7.3") With –M model: Ø 70 mm × 181.6 mm (Ø 2.8" × 7.1")

Weight

Without –M model:

Camera: Approx. 270 g (0.6 lb.)

With package: Approx. 510 g (1.1 lb.)

-M model:

Camera: Approx. 390 g (0.9 lb.) With

package: Approx. 630 g (1.4 lb.)
